| How to order | ||
| SZU10N -LA4 -M5M ① ② ③ | ||
| ① Model | ② Vacuum port direction | ③ Mounting thread |
| SZU10N SZC SZB SZD | Nil - Vertical LA4 - Lateral, one touch fittingφ4 hose LA6 - Lateral,one touch fittingφ6 hose | M5M - M5×0.8 Male thread M6M - M6×1 Male thread M8M - M8×1Male thread M5F - M5×0.8 Female thread M8F - M8×1.25 Female thread |
| Selection | ||||||||
| Diameter | Vacuum port direction | Mounting thread | ||||||
| Nil | LA4 | LA6 | M5M | M6M | M8M | M5F | M8F | |
| 2-8 | ● | ● | ● | ● | - | - | ● | - |
| 10-16 | ● | ● | ● | ● | - | - | ● | - |
| 20-32 | ● | ● | ● | - | ● | - | ● | - |
| 40-50 | ● | - | ● | - | - | ● | - | ● |
◇Note: "●"- standard, in stock. "—"-unavailable.
